0.005mm Precision Custom Peek Parts Filled With Carbon Fiber Anti Corrosion

shenzhen jiajingyuan electronic technology co.,ltd
Contact Now
    Buy cheap 0.005mm Precision Custom Peek Parts Filled With Carbon Fiber Anti Corrosion from wholesalers

    Buy cheap 0.005mm Precision Custom Peek Parts Filled With Carbon Fiber Anti Corrosion from wholesalers
    • Buy cheap 0.005mm Precision Custom Peek Parts Filled With Carbon Fiber Anti Corrosion from wholesalers
    • Buy cheap 0.005mm Precision Custom Peek Parts Filled With Carbon Fiber Anti Corrosion from wholesalers
    • Buy cheap 0.005mm Precision Custom Peek Parts Filled With Carbon Fiber Anti Corrosion from wholesalers

    0.005mm Precision Custom Peek Parts Filled With Carbon Fiber Anti Corrosion

    Ask Lasest Price
    Brand Name : oem odm
    Price : Negotiated
    Payment Terms : T/T
    Supply Ability : 10000PCS
    Delivery Time : 20 days after 2D 3D confirmed
    • Product Details
    • Company Profile

    0.005mm Precision Custom Peek Parts Filled With Carbon Fiber Anti Corrosion

    Custom Peek Parts Filled with Carbon Fiber

    Model NO.
    PEEK Machined Parts
    Density
    1.3-1.6g/cm3
    Transport Package
    CTN, Plt and Others
    Specification
    Actual packaging
    Trademark
    Jiajingyuan
    Origin
    China
    Production Capacity
    10000

    Textile machinery to deal with high-speed, oil-free and corrosion-resistant, hydrolysis requirements, PEEK, PI successfully replace the existing ceramic, metal and all kinds of ordinary plastic, and brings superior performance for textile machinery parts, higher reliability and productivity. Such as: Air-jet looms wearable spool, self-lubricating wear-resistant sleeve, high temperature resistant slider track plate, oil-weaving shuttle, sword round.

    The company has CNC machining centers, CNC lathes, molding machines, precision injection molding machine, engraving machine, ultrasonic welding, continuous extrusion PEEK plate rod tube and so improve the process conditions and experience. Have friction and wear testing machine, universal testing machine mechanics, surface roughness tester, projector, surface hardness, and other detection equipment, product quality control PEEK parts provide a reliable guarantee. Equipped with laser marking machine, according to customer requirements of your company name, logo, free marked on PEEK parts, batch or flow identification marks such as text or graphics. PEEK plate rod tube with a continuous extrusion production lines, PEEK plate, PEEK pipe and PEEK rod tube sizes have become standardized, serialized, common specifications spare inventory.



    1. PEEK series Data sheet

    PEEK Series Data Sheet
    ItemTest StandardUnitPEEK5600GPEEK5600GF30PEEK5600CF30PEEK5600LF30
    ColorNatural or BlackNatural or BlackBlackBlack
    DensityISO 1183g/cm31.3±0.011.5±0.011.4±0.011.43±0.01
    Water Abs. (25ºC.24Hrs)ISO 62%0.50.110.060.06


    Mould shrinking percentage
    ISO 294
    3mm,170ºC, Flow direction
    %1.20.40.10.3
    ISO 294
    Perpendicular to flow direction
    %1.50.80.50.5
    Melting pointISO 11357ºC343343343343
    Distortion temperatureASTM D648ºC163315315293
    Continuous using temperatureUL 74685ºC260260260260
    Coefficient of thermal expansionASTM D69610-5ºC4.72.21.52.2
    Tensile strength(23ºC)ISO527-2/1B/50MPa100155220134
    Tensile elongation(23ºC)ISO527-2/1B/50%3421.82.2
    Bending strength(23ºC)ISO 178MPa163212298186
    Compressive strength(23ºC)ISO 604MPa118215240150
    Lzod impact strength ( no gap)ISO 180/UkJ·m-2No crack514632
    Rockwell hardnessASTM D78599103107102
    Flammable levelUL 94V-0 @mm1.51.51.50.75
    Dielectric strengthIEC 248KV/mm1.81.9
    Dielectric constantIEC 2503.23.3
    Surface resistivityΩ1015Ω1015Ω3×106Ω5×106Ω
    Friction coefficientASTM D3702μ0.30-0.380.38-0.460.30-0.350.15-0.20
    If need other parameter, please contact us!
    PEEK5600G: 100%PEEK
    PEEK5600GF30: 30% glass fiber + 70% PEEK
    PEEK5600CF30: 30% carbon fiber + 70% PEEK
    PEEK5600LF30: 10% carbon fiber + 10% PTFE +10% graphite

    Different grades have different working environments. PEEK-pure has better toughness and is suitable for use in the sealing industry. The added glass fiber can provide PEEK material with certain strength without affecting its electrical properties. It is widely used in Textile printing and dyeing industry; adding carbon fiber can provide PEEK material with high mechanical strength and good wear resistance, suitable for use in beverage filling and other industries; PEEK-FC30 is widely made into the wear-resistant parts.
    2. Product specification

    Production Specification
    Product NamePure PEEK sheet
    MaterialPure PEEK
    ColorNatural
    SizePlease see the below table
    Manufacturing TechniqueExtrusion, compression molding
    CertificationISO9001,SGS, FDA, ROHS
    SampleTo be negotiated
    PackageWooden case or carton

    PEEK material performance
    PEEK is a semicrystalline thermoplastic with excellent mechanical and chemical resistance properties that are retained to high temperatures. PEEK is used to fabricate items used in demanding applications, including bearings, piston parts, pumps, HPLC columns, compressor plate valves, and cable insulation. It is one of the few plastics compatible with ultra-high vacuum applications.
    PEEK is second only in PI in special engineering plastics, but PEEK has better processability and wider processing window than PI to become a cost-effective engineering plastic. PEEK materials are often selected as the highest priority material between 120 and 260 °C.


    What we do:

    • High precision mold design and manufacturing
    • Mold Temperature Controlling Machine Design and Manufacturing
    • Plastic Injection Production
    • Product Total Solution Provider
    • Game Station accessories design and manufacturing
    • Electronic Products Design and Manufacturing
    • Mirror or Texture Molds Design and Manufacturing
    • Home Appliance Molds Design and Manufacturing
    • Medical Product Molds Design and Manufacturing
    • Automobile Interior Parts and Precision Accessory Design and Manufacturing
    • Daily Skin Care Package Molds Design and Manufacturing
    • Painting Free Injection Parts design and manufacturing
    • Home Appliance Frames design and manufacturing
    • Rich Fiber Parts design and manufacturing
    • Plating Parts design and manufacturing
